1.8

6.8

1800

1800

1800

LF/RF Series and LFD/RFD Series Cartridge Pumps

Pressure: 150 PSI Max

Stripped Lubricaion Pumps

Pressure: 300 PSI Max

TR Series Lubricaion Pumps

Pressure: 140 PSI Max

Pressure: 300 PSI Max

D Series Pump

316 Stainless Steel, Hastelloy or Titanium; Flow rates to 121 gph (458 L/hr), differential pressures to 250 psi (17.2 bar), system pressures to 500 psi (34.5 bar), temperatures to 350°F (176°C), viscosities to 2000 cps +.

T Series Pump

316 Stainless Steel or Hastelloy; Flow rates to 650 gph (2460 L/hr), differential pressures to 250 psi (17.2 bar), system pressures to 500 psi (34.5 bar), temperatures to 350°F (176°C), viscosities to 2000 cps +.

P Series Pump

PPS Engineered Polymer; Flow rates to 63 gph (238 L/hr), differential pressures to 130 psi (9 bar), system pressures to 300 psi (20 bar), temperatures to 150°F (65°C), viscosities to 1000 cps +.

W Series Pump

Water and Wastewater Chemical Metering Pumps, flow rates from < 1 ml/min to 10 GPM (38 LPM), differential pressures to 250 psi (17.2 bar), accuracy better than 1%

Variable Flow Drive - 0V1V

Analog Remote Pump Drive

Variable Flow Drive - 4V5V

Adjustable Current and Acceleration and Signal Following

Variable Flow Drive - 2V3V

Analog Remote Pump Drive... Adjustable Current and Acceleration

Variable Flow Drive - 8V9V

Digital Remote Pump Drive

Global Gear Process Pumps

Back pull-out design provides ease of maintenance. Flow rates to 550 usgpm (124.9 m 3 /hr). Pressures to 200 psi (13.8 bar). Viscosities to 1,000,000 ssu (220,000 cst).

Models: GG015, GG030, GG050, GG070, GG080, GG090, GG120, GG130, GG200, GG210, GG250, GG500 and GG550

Heavy-Duty Process Pumps

Magnetically Coupled - MagDrive Process Pumps

316 Stainless Steel or Hastelloy; Flow rates to 650 gph (2460 L/hr), differential pressures to 250 psi (17.2 bar), system pressures to 500 psi (34.5 bar), temperatures to 350°F (176°C), viscosities to 2000 cps +.

Models: ML0I, ML1I, ML2I, MC2I, MC3I, MC4I, MC5I, MC6I, MG015I, MG030I, MG080I, MD015S, MD030S and MD080S

Liquid Recirculation Chemical Pumps

Chemical Pumps to transfer from standard minibulks and tanks with liquid recirculation. The SS445 12 V DC Diaphragm Pump provides effective chemical transfer, recirculation and real pumping power at any temperature.

Models: SS445 and SS445X771

Mini Bulk Chemical Pumps

AC and DC Chemical Transfer Pumps designed for the transfer of farm chemicals, professional products and industrial fluids. Transfers thin to thick products including slurries and encapsulated chemicals. Rugged chemical compatible materials of construction with patented design to cut amp draw and extend motor life.

Models: SS417, SS420, SS421, SS460 and SS461

Portable Chemical Pumps - Chemtraveller

AC and DC Chemical Transfer Pumps designed for the transfer of farm chemicals, professional products and industrial fluids. Transfers thin to thick products including slurries and encapsulated chemicals. Rugged chemical compatible materials of construction with patented design to cut amp draw and extend motor life.

Models: SS435 and SS465

300V AC PUMPS

Models: FR300, FR301, FR310, FR311

400 Pumps 115/230VAC

Models: FR450

700 Pumps 115/230VAC

Models: FR700, FR701

600 AC Pumps

Models: FR610C, FR611C

Series 300 AST Systems

The Series 305 Compact Remote Dispenser provides convenience and safety for above ground storage tank applications. It can be installed at a user-friendly height while the pumping unit remains on top of the tank. For flexible flow rates and applications, combine remote dispensers with Fill-Rite above ground pump Series 303, 313 or FR713.

Models: 305R and FR305R

Series 700B and 300

The heavy-duty, positive displacement pumps deliver up to 30 GPM (114 LPM) and are designed with Fill-Rite's exclusive anti-siphon safety feature. For flexible and convenient applications, combine above ground pumps with Series 305 or 307 remote dispensers.

Models: FR713, 303 and 313

Series 700B AST Systems

A compact, "fancy" utility pump for use with above ground storage tanks. The RU (rear outlet, universal nozzle boot) model comes with a Series 800C flow meter and can be equipped to pump a variety of fuels from 5 to 18 GPM (19 to 68 LPM).

Models: FR702R and FR702F

FR1602 DC Gear Pumps

Models: FR1602

FR1604 DC Duel Voltage Pumps

Models: FR1604

1200C DC Pumps

Models: FR1205C, FR1210C, FR1211C, FR2410C, FR2411C

400 DC Pumps

Models: FR410, FR210, FR212

4200 DC Fuel Pumps

Models: FR4210, FR4211, FR4410, FR4411

Hand Lever Piston Pumps

Hand Lever Piston and Air Operated Pump Series 20 The economical way to transfer tough industrial fluids easily, safely and accurately. Perfect for barrels, storage tanks and drums, the FR20 Hand Lever Piston Pump transfers at approximately 11 fl. oz. (325ml) per stroke.

Models: FR20 and FR20V

Heavy-Duty Rotary

Rotary Hand Pumps Series 100 Especially effective with medium viscosity liquids, as well as oils, gasoline and diesel fuels, the rotary action of these easy-to-use pumps allows smooth, continuous transfer at up to 10 GPM (38 LPM) per 100 revolutions.

Models: 110, 112, 113 and 114

Heavy-Duty Quart Stroke

Quart Stroke Hand Pump Series 30 Reliable pumps that are field calibrated to accurately dispense a quart or liter with each handle rotation. Standard swing return drain tube eliminates messy work area.

Models: 31

Piston Hand Pumps

Piston Hand Pump Series 5200 This compact, high flow, dual-action design delivers up to 20 GPM (76 LPM) per 100 strokes. Lightweight and portable, with a variety of options, these pumps meet a full range of applications. Ideal for gasoline, oil or a wide variety of approved liquids.

Models: FR150-1, FR150, FR151 and FR152

Rotary Vane Hand Pump

Model SD62 This easy to use hand-operated rotary vane pump delivers approximately 6 gallons (23 liters) per 100 revolutions- dependably and quickly.

Models: SD62

Italia Model Fix UP

This Transfer Station Kit is equipped with the PA1 - 230V, 50 Hz rotary vane pump, aluminum nozzle with 1" female brass swivel fitting, 4 M X 19 MM rubber delivery hose with brass ends, metal telescoping shaft and a 2" ring nut. The Model Z98 mechanical meter is available as an option.

Model: Fix-up

Italia Model E 220-35

These self-priming 230V AC eccentric pump with by-pass valve include a fan cooled - ventilated AC motor with IP 55 protection and a die-dast aluminum pump body. Flow rates will vary according to viscosity and other working conditions. Especially suited for extracting used oil from motor vehicles.

Model: E200-35

Italia Model LIGHTPUMP 60-80-100

These Transfer Station Kits are available with the PA1 or PA2 - 230V or 115V, 50 or 60 Hz rotary vane pumps, aluminum nozzle with 1" female brass swivel fitting, 4 M rubber hose X 19 MM for the PA1 (25 MM for the PA2) with brass ends. Flow rates are from 59 to 100 LPM.

Model: Lightpump

Italia Model BASE

Compact high speed diesel fuel distributors are equipped with the Model PA1or PA2 230V or 115V, 50 Hz or 60 Hz self-priming, rotary vane pumps. The Distributors are mounted on anti-vibration supports, include a volumetric mechanical flow meter, nozzle hanger with on/off switch, aluminum nozzle with 1" female brass swivel fitting and a 4 M X 19 MM rubber delivery hose with brass connections. The case structure is stamped metal with anti-corrosion treatment and painted for outside use. Flow ranges from 57 LPM to 95 LPM.

Models: Base

Italia Model HI-FLO

These Transfer Stations Kits are available with the PA1 or PA2 - 230V or 115V, 50 or 60 Hz rotary vane pumps, Model Z98 mechanical meter, aluminum nozzle with 1" female brass swivel fitting, 4 M rubber hose X 19 MM for the PA1 (25 MM for the PA2) with brass ends. The units utilize a panel that is treated for corrosion and painted for outdoor use and an integral nozzle holder. These Transfer Kits can be mounted either wall hung or free standing. Flow ranges are from 58 to 75 LPM.

Models: Hi-Flo

Italia Model PA1 and PA2

Self-priming, rotary vane pumps designed for the transfer of diesel fuel. These pumps are equipped with self ventilating induction AC motors in 230V or 115V, 50Hz or 60Hz configurations - all with IP 55 protection, class F insulation and thermal protection. A by-pass valve is located in the pump body. The pump casting is cast iron treated against corrosion and painted. The pump rotor is sintered steel with a Stainless Steel strainer built into the pump body. Flow Ranges from 60 LPM to 105 LPM - available with 1" ports.

Models: PA-1 and PA-2

Italia Model VISION 60-80-100

These Delivery Stations are available in 3 colors and corresponding flow rates: Yellow - 57 to 60 LPM (VISION 60), Blue - 72 to 80 LPM (VISION 80) and Red - 92 to 95 LPM (VISION 100). All models are equipped with self-priming, AC rotary vane pumps with integrated by-pass and strainer. The self ventilating induction motor has IP 55 protection, class F insulation and thermal protection located in the windings. The pump and motor are installed on an anti-vibration support. Also, included in the Distributors are a volumetric mechanical flow-meter, 4 M X 19 MM rubber delivery hose with brass ends, automatic nozzle with a brass swivel fitting. The Vision Fuel Distributors are easy to maintain, operate and contain an automatic switch for quick and safe operation.

Model: Vision

DC Pump Model ECOKIT

These self-priming, rotary vane pumps are available with 12V or 24V enclosed DC motors. Motors have IP 55 protection. A by-pass valve is incorporated in the pump body. Included is a "bolt on" pump support bracket. Flow capacities are 40 LPM (12V) to 42 LPM (24V) - with 3/4" ports. Carrying handle, on/off switch, 2 M cable with battery clips and fuse are standard in these models.

Model: ECOKIT

DC Pumps Model ECOKIT 1-3-4

All models of these Transfer Kits are equipped with a 12V or 24V DC self-priming - electric rotary vane pump with by-pass, suction strainer and 2 M suction hose, on/off switch, cable with battery clips and fuse. Kits incorporate 4 M X 19 MM rubber delivery hose with brass ends and aluminum nozzle with 1" female brass swivel fitting. Flow ranges are from 38 to 60 LPM.

Model: ECOKIT 1-3-4

DC Pumps Model GTE

Diesel oil transfer kit includes the Model E 12V or 24V eccentric pump, 4 M X 19 MM PVC hose with suction strainer, plastic nozzle with swivel and inlet/discharge fittings. Flow ranges of 30 - 40 LPM. Standard with metal case.

Model: GTE

DC Pumps Model Kit Batteria

These Diesel Transfer kits include the Model KPT 12V or 24V self-priming DC vane pumps. Kits incorporate 4 M X 19 MM rubber delivery hose with brass ends, suction strainer and aluminum nozzle with 1" female brass swivel fitting. Standard with plastic carrying case - metal case optional. Flow rated at 40 - 42 LPM.

Model: BATTERIA

DC Pumps Model P

Self-priming, positive displacement, dual voltage - 12V or 24V DC - rotary vane pump incorporates the bypass in the pump body, on/off switch, suction strainer and cable with battery clips. Flow ranges of 45 LPM on 12V and 60 LPM on 24V. Pumps are standard with metal case.

Model: P

DC Pumps Model PB and PB1

These self-priming, rotary vane pumps are available with 12V or 24V enclosed DC motors. Motors have IP 55 protection and 30 minute intermittent duty cycle. By-pass valve and Stainless Steel strainer are incorporated in the pump body. Included is a bolt on pump support bracket. Flow ranges form 45 LPM to 60 LPM - with 1" ports. Carrying handle, on/off switch, 2 M battery cable with clips and fuse are standard in the PB1 Models. The 60 LPM - PB1 pump models are available with a metal cover.

Model: PB and PB1

DC Pumps Model E

Self-priming 12V or 24V DC eccentric pump with by-pass, on/off switch, cable with battery clips and suction strainer. Flow ranges of 30 - 40 LPM. Standard with metal case.

Models: E

DC Pumps Model GLP

Diesel oil transfer kit includes the Model P dual voltage - rotary vane pump, 4 M X 25 MM PVC hose with suction strainer, aluminum nozzle with 1" female brass swivel fitting and inlet/discharge fittings.

Models: GLP

Italia Model PA1 and PA2

Diesel oil transfer kit includes the Model P dual voltage - rotary vane pump, 4 M X 25 MM PVC hose with foot valve, aluminum nozzle with 1" female brass swivel fitting and inlet/discharge fittings. This kit incorporates the Model Z98 aluminum mechanical flow meter

Models: GTP

DC Pumps Model KPT

Self-priming 12V or 24V DC rotary vane pump with IP 55 motor protection, by-pass incorporated in the pump body, on/off switch, cable with battery clips and fuse. Flow ranges of 40 - 42 LPM with 3/4" hose connections. Standard with plastic carrying case - metal case optional. Flow rated at 40 - 41 LPM.

Model: KPT

DC Pumps Model PAI

Self-priming 12V or 24V DC transfer gear pumps for use with light oils, diesel fuel, kerosene, antifreeze and water. Bronze gears and 3/8" BSP inlet/outlet hose barbs accommodates 14 MM diameter hose. These pumps include stainless steel shaft, permanent magnets with brushes and IP 55 protection on motor, brass pump body, in-line strainer, power cable and battery clips. Flow rated at 14 LPM.

Models: PAI

DC Pumps Model PTP

These Diesel Transfer kits include the Model KPT 12V or 24V self-priming DC vane pumps. Kits incorporate 4 M X 19 MM rubber delivery hose with brass ends, suction strainer and aluminum nozzle with 1" female brass swivel fitting. Also, includes, telescoping suction tube, ring nut and plastic carrying case - metal case optional.

Models: PTP

DC Pumps Model Wall Station

These 12V or 24V Diesel Fuel Transfer Stations are designed for wall mounting. All models are equipped with a Model Z98 mechanical meter, self-priming - DC rotary vane pumps with by-pass and suction strainer, on/off switch, cable with battery clips and fuse. Kits incorporate 4 M rubber delivery hose (19 MM for the 38 - 40 LPM models and 25 MM for the 42 - 57 LPM models) with brass ends and aluminum nozzle with 1" female brass swivel fitting.

Model: WALL STATION

LP Bulk Oil Pumps

The LP Bulk Transfer pumps are designed specifically to transfer bulk oils, hydraulic fluid and antifreeze or antifreeze mixes. A high horse power-to-flow ratio assures adequate power to pump viscous fluids at low temperatures. The pump mounts on a standard barrel bung and is shipped with a quick-detach adapter. The pump has an internal bypass valve to bypass flow if the discharge pressure exceeds the bypass valve setting.

Models: LP200P18Q and LP200P36Q

LP Kit Pumps

The LP Kit pumps - Weather resistant electric motors with a smaller displacement gerotor gear pump assure adequate power to pump viscous fluids at low temperatures. The pump kit mounts on a standard barrel and comes complete with mounting bracket, hose, nozzle, quick-detach adapter and suction pipe. The pump can also be used for transferring waste oil.

Models: LP200P18Q, LP200P36Q and LP50P18Q12

LP on Demand Dispensers

The LP On-Demand series dispensing pumps are a unique new system for dispensing oil, gear lube and antifreeze without the problems of air-operated systems. The LP On-Demand pump employs a gerotor gear design driven by an electric motor to dispense the fluid. A pressure sensing system is utilized to start the pump when the hose end valve is opened. It also stops the pump when the hose end valve is closed, blocking flow.

Models: LP450P10Q and LP650P10Q

No Contact between operating components in the casing. Flat power curve over entire vacuum range prevents motor overload. Reduced stress on motor shaft and bearing. Increased water handling capacity prevents heat build up, extends life of mechanical seals. Flows to 600 CFM. Vacuum levels to 29" Hg (25 Torr / 33 mbar abs).

Models: A5, A10, A15, A20, A75, A100, A130, A200, A300

The T-Series multi-stage liquid ring vacuum pump utilizes the same axial flow design as the A-Series single stage pump with an additional stage to achieve deeper vacuum levels.

Models: T0505, T1505, T7530, T10030

Kinney SDV dry screw vacuum pumps operate without oil or water in the pumping chamber, and due to straight through design, the SDV handles both condensable vapors and some solids without leaving residue. There is no metal-to-metal contact inside the pumping chamber, so wear is minimized.

Models: SDV120, SDV200, SDV320, SDV430, SDV800

Kinney KLRC liquid ring vacuum pumps are ideally suited for pumping wet mixtures and even slugs of liquid.

Models: KLRC40, KLRC75, KLRC100, KLRC125, KLRC200, KLRC300, KLRC525, KLRC526, KLRC775, KLRC776, KLRC950, KLRC951

KC Series Vacuum Pumps

Kinney KC rotary piston vacuum pumps achieve the lowest possible pressures from mechanical pumps and are recommended for applications where the operating pressure is below 0.1 Torr (0.13 mbar).

Models: KC5, KC8, KC15

KT Series Vacuum Pumps

KT pumps are quiet running vacuum pumps with high pumping capacity at both high and low pressure. The triplex piston design is practically vibration free.

Models: KT150, KT300, KT500, KT850

KD and KDH Series Vacuum Pumps

KD and KDH vacuum pumps are belt-driven, low speed rotary piston pumps. Since these pumps have no metal-to-metal contact from the clearances being filled with oil, these pumps are rugged and reliable.

Models: KD30, KD50, KDH130, KDH150

KTC Series Vacuum Pumps

Kinney KC rotary piston vacuum pumps achieve the lowest possible pressures from mechanical pumps and are recommended for applications where the operating pressure is below 0.1 Torr (0.13 mbar).

Models: KTC21, KTC60, KTC112

KT-LP Series Vacuum Pumps

KT-LP pumps are quiet running vacuum pumps with high pumping capacity at both high and low pressure. The triplex piston design is practically vibration free.

Models: KT170LP, KT275LP, KT505LP, KT840VFP, KT1350VFP

KVAC Series Vacuum Pumps

KVAC rotary vane vacuum pumps are utilized in laboratories and industry. All models include gas ballast valves and KF flanges.

Models: KVAC2, KVAC5, KVAC10, KVAC15, KVAC21, KVAC33, KVAC63

KVA-KVAH Series Vacuum Pumps

Kinney oil-flooded, multi-vane vacuum pumps are single stage, air cooled and direct driven.

Models: KVA12, KVA21, KVA25, KVA40, KVA63, KVA100, KVA160C, KVA250D, KVA400C, KVA630C, KVAH25, KVAH40, KVAH63, KVAH100, KVAH160C, KVAH250D
